SS-670/850/280-PM-S-R7035

Control cabinets with mounting plate, SS-670/850/280-PM-S-R7035, solid doors, single door, 670x850x280mm (WxHxD), Magnelis®, structured, RAL7035

Request for quotation
  • control cabinets provide complete and effective protection against external factors for electrical installation components, controllers and all kinds of control equipment and systems,

  • allows for the organization and systematization of advanced electrical equipment,

  • ensures the safe operation of the electrical system or equipment,

  • protects against interference by unauthorized persons,

  • rack cabinet equipped with doors locked with a key, key code depending on preferences can be repeatable or different,

  • possibility to produce from Magnelis®, stainless steel, or acid-resistant steel,

  • Magnelis® sheet is the only metallic coating certified for use in a C5 environment, which provides durability and protection against corrosion.

Technical specification

application
power industry
dimensions (width x height x depth)
670mm x 850mm x 280mm
cable entry type
multigate grommet HTKC-43-TPE
cable entry dimensions
190mm x 60mm
number of cable entries
2x rear
door type
solid
number of doors
1
thermostat
equipment ordered separately
grounding details
doors
mounting type
indoor, wall-mounted
operation temperature range
-40°C to +70°C
ingress protection degree IP
IP 54
impact protection degree IK
IK 10
flammability class
V0 acc. UL 94
weight
~35.0 kg
material
powder painted Magnelis® sheet
color
structural, light grey RAL7035
standards and certificates
ISO 9001:2015, PN-EN 60529, PN-EN 62262, REACH Regulation No 1907/2006/EC, RoHS 2011/65/UE
